If you’ve dropped your house key in tall grass, you know how difficult it is to locate a small item hiding in an overgrown field. Perhaps, you borrowed a metal detector from a friend, then returned to the field hoping to get the loud beep that indicates finding metal in an otherwise organic area.
Trying to find patterns in strings of data is the same process. However, instead of using a physical object, you use a regular expression (regex) to search for the key patterns that would find the data elements you want.
While regex is a well-known syntax across various programming languages, having an understanding of what it is and how to use it can help you be more efficient when trying to match patterns or manipulate strings.
What does regex mean?
Regex is short for regular expression, a specialized syntax for defining search patterns when matching and manipulating strings. Unlike simple wildcards, regex offers advanced capabilities that allow for flexible definitions to create narrow or broad searches across:
- Data filters
- Key event
- Segments
- Segments
- Audiences
- Content groups
A regular expression engine processes the regex partners, performing the search, replacement, and validation. However, since regex is not limited to a single programming language, the regular expression engine for a specific language may have its own unique requirements.
The core components include:
- Atoms: elements within the expressions
- Metacharacters: definitions of grouping, quantification, and alternatives
- Anchors: starting and ending points for a string or line
- Character classes: specific characters defined within a search pattern
- Quantifiers: number of characters or character classes to be matched
- Alternation: number of possible search patterns to be matched
What is a regex function used for?
Regex syntax is part of standard programming libraries so that programmers can define compact search patterns. Some typical uses include:
- Pattern matching: identifying substrings within input strings that fit defined patterns
- Search and replace: modifying strings by replacing the matched patterns with replacement strings
- Validation: reviewing to ensure that input strings follow defined formats
- Data extraction: retrieving data points from large bodies of text
- Parsing: breaking strings into their components
Writing a Regular Expression
At their core, a regex pattern is a sequence of atoms, where each atom represents a single point that the regex engine attempts to match in a target string. These patterns can range from simple literal characters to complex formations involving grouping symbols, quantifiers, logical operators, and backreferences. Many tools are available to debug your regex patterns.
Simple Patterns
Some regex patterns typically require a precise match for defined characters. For example, here are a few common text and data structures and some regex patterns:
Regex Patterns Table
| Pattern Name | Regex | Matches |
| Email Address | [a-zA-Z0-9._%+-]+@[a-zA-Z0-9.-]+\.[a-zA-Z]{2,} | [email protected], [email protected], [email protected] |
| Match a U.S. Phone Number | \(\d{3}\) \d{3}-\d{4} | (123) 456-7890, (987) 654-3210 |
| Match IPV4 IP Addresses | \d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3} | 192.168.1.1, 255.255.255.0 |
Escaping
Escaping in regex uses a backslash (\) to treat special characters as literals, ensuring they are interpreted correctly by the regex engine. Escaping is only necessary at the string literal level when dealing with characters that have special meanings, such as . or *. However, for a simple string like “ily”, no escaping is required since it contains no special characters.
Special characters
Special characters in regex provide additional matching capabilities beyond literal sequences.
For example, if you want to match a Windows file path that starts with C:\, you need to properly escape the backslash (\) since it is a special character in regex. The correct regex pattern would be C:\\ to match C:\ exactly. If you want to match a full file path like C:\Users\jdarr\Documents, the regex would be C:\\Users\\jdarr\\Documents. Similarly, if you want to match a file extension (e.g., .txt), you must escape the period as \.txt, since . is a wildcard in regex.
Parentheses
Parentheses in regex are primarily used to create capturing groups, which allow specific parts of a match to be referenced later. This is particularly useful for backreferences and substitutions. For example, in the regex pattern (\d{3})-\1, the first (\d{3}) captures a three-digit number, and \1 ensures that the same number appears again, matching values like 123-123 but not 123-456. If you need to group elements without capturing them, you can use non-capturing groups with (?:…), which helps structure complex patterns without affecting backreferences.
Matching characters
Most characters in regex match themselves, meaning that the pattern test searches for this exact sequence within strings. Combining literal characters and metacharacters allows you to create more complex patterns for matching, like defining case sensitivity for letters.
Repeating Things
Using metacharacters, you can create more complex searches that also allow for repetition within a sequence. The * metacharacter signifies that the preceding character can match zero or more times, while + ensures one or more matches.
Using Regular Expressions
Regex engines expand upon these fundamentals so that you can more easily manipulate text and search within your programming and data processing.
Programming Languages
While you can use regex with any programming language, you should be aware that each language has its own idiosyncrasies. For example, if you have a working regex in Python then try to convert it to Java, you can have issues arising from the different implementations.
The Backslash Plague
When you use the backslash as an escape character, you can have a long list of backslashes that make the expression more complex. For example, if you use the backslash as a string literal and an escape, then the expression typically requires double escaping (\\). As your expressions get longer, you can lose track of the number of backslashes necessary which can impact the ability to match.
Match and replace
Regex patterns are integral for searching specific sequences within input strings. These methods, versatile with optional parameters, enhance the capability for fine-tuned searching, validation, and replacements.
For example, if you want to match a pattern to replace sensitive information in a log, you might want to use a regex expression like:
regex_replace(pattern: string, value: string, replacement: string,[replace_all: boolean])
To replace a person’s name with an anonymous identifier, you might write this:
// message = ‘logged in user: mike’
let username = regex_replace(“.*user: (.*)”, to_string($message.message), “$1”);
// message = ‘logged in user: mike’
let string = regex_replace(“logged (in|out) user: (.*)”, to_string($message.message), “User $2 is now logged $1”);`
